Mechanical Parking
We will provide optimal solutions for the entire parking life cycle “SMART Solution”.
We believe that superior planning and consulting are indispensable as well as providing high-quality parking facilities for the realization of safe, easy-to-use and efficient parking.
- Mechanical Parking
- “Mechanical parking lot” refers to an off-street parking lot and affiliated parking lot equipped with equipment to move cars to the parking place by mechanical devices. Mechanical parking lot is divided into PALLET type and FORK type.
- PALLET Model
- This is the basic form of a mechanical parking lot incorporating passenger elevator technology.
- FORK Model
- It is a form that adds safety to the advantages of the existing PALLET Model. Structural safety was designed with top priority to minimize vibration and noise transmitted to adjacent buildings.
PALLET Model
Cart Parking
-
Summary
- Elevators and bogies are operated simultaneously, reducing boarding and disembarking time and facilitating installation of entrances and exits.
-
Features
- Parking space can be increased by installing an additional elevator
- Reduction of time by forward entry (or exit) when installing Built-in turntable
- Efficient response to vehicle flow plan by enabling flexible arrangement of entrance and exit locations
- Various models including built-in turntable
Trolley Parking
-
Summary
- It is a method of loading and unloading by means of lifts formed vertically from the car storage floor to the parking floor and trolleys that run independently on each level of the parking floor. It is possible to flexibly arrange the entrance and exit locations to efficiently respond to basement space utilization and vehicle circulation planning.
-
Features
- Up to 100 lifts can be accommodated per lift
- The number of parking spaces can be increased by installing additional lifts
- Reduction of time by simultaneous warehousing and warehousing of the pallet-free method (average 1 minute)
- Semi-permanent and easy to repair and inspect when forming parking lot concrete
- Construction period can be shortened when steel frame is formed in the parking lot
- Reduction of time by advance warehousing (shipping) when turntable is built in
Translator Parking
-
Summary
- By simultaneously lifting and driving, it is a method of loading and unloading cars in the left and right parking spaces like an automated warehouse. Since the location of the entrance and exit can be installed on any floor, it is possible to utilize the underground space and arrange the flow line smoothly.
-
Features
- Up to 100 lifts can be accommodated per lift
- The number of parking spaces can be increased by installing additional lifts
- Reduction of time by simultaneous execution of lifting and driving (average 1 minute)
- Semi-permanent and easy to repair and inspect when forming parking lot concrete
- Construction period can be shortened when steel frame is formed in the parking lot
- The floor height required for the parking lot is low (1,900mm), so when planning a new building, it is possible to reduce the height of the basement floor and maximize its utilization.
Free Parking
-
Summary
- The free parking lot is mainly used by the general public, and it is an economical system that can use a parking space several times wider by using a prefabricated lightweight steel frame.
-
Features
- The installation period is short, so the existing parking lot can be used to the maximum
- Lightweight prefabricated steel structure, easy to assemble and dismantle, and inexpensive
- Self-propelled, no power cost and economical
- Possible to permit as a workpiece (8m or less)
- Excellent effect in factories, parks, airports, resorts, department stores, and temporary parking lots
Box Parking
-
Summary
- It is a multi-step rotation method based on the principle of lifting and conveyor by arranging pallets in a row and repeating lifting and conveying. It is suitable for small buildings and multi-story installation of 2 to 6 layers is possible.
-
Features
- High efficiency space utilization of narrow land
- Various models including built-in turntable
FORK Model
Elevator Parking
-
Summary
- It is characterized by installing a lift by placing a pallet in the center of the tower and moving the pallet left and right after boarding the vehicle. The latest elevator system and low-noise, low-vibration operating system allow you to experience cutting-edge technology that enables high-speed driving.
-
Features
- Convenience for drivers
- Low noise, low vibration and eco-friendly
- Entry and exit of a single-axis car with high-speed running of 90m/min ~ 145m/min
- Easy access to vehicles with built-in turntable
- Depending on the installation method, access method, and location conditions, it is possible to select the appropriate model
Puzzle Parking
-
Summary
- Continuous installation of each unit is possible according to the site conditions by the method of loading and unloading by repeating the lifting and traversing motion of the upper and lower pallets.
-
Features
- Good space efficiency
- Fast arrival and departure time
- In case of unit failure, other units can operate normally
